350 XC-F 2022

KTM 350 XC-F 2022 for Sale at Virginia KTM in Virginia, QLD | Specifications and Review Information
NO COMPROMISE
The KTM 350 XC-F merges an aggressive motocross personality, with a refined and forgiving chassis setup. That results in a machine that feels like a 250 but kicks up dust like a 450 - with the handling characteristics of an out-and-out racer. In short, it's one of the most complete offroad weapons in the KTM arsenal.

ENGINE
The DOHC engine of the KTM 350 XC-F features a compact and lightweight 60 lbs construction, complete with lightweight titanium valves and DLC coated cam followers. THis makes for lively, but strong engine characteristics with a high rev ceiling. Fitted with the latest electronic fuel injection system and an E-starter, it has an extremely wide usable speed range, high performance, and incredibly efficient rideability.

EXHAUST
When it comes to power delivery and performance, the exhaust on all 4-stroke models plays a key role and packs a punch that is hard to beat. It features a model-specific header pipe with an advanced resonator called FDH (Flow Design Header), which is a small chamber around the pipe. The design allows the exhaust to be disassembled without removing the shock absorber, providing easier access to the shock. The aluminum sleeve, end cap, and internal design of the silencer also allow for slimmer ergonomics, making the bike feel slimmer, without compromising regulatory noise limits.

FRAME
The KTM 350 XC-F is built around a high-tech, lightweight chrome-moly steel frame, which provides class-leading levels of handling, rideability, precision, and stability. Designed to take the hardest of hits, the frame itself acts as a shock absorber for the front and rear suspension, soaking up any jumps and jolts. The frame also features an extra-light subframe made of aluminum, which tips the scales at less than 2 pounds, keeping the weight low and the speed stellar.

WHEELS
The KTM 350 XC-F is fitted with a lightweight set of high-end wheels, consisting of CNC-machined hubs, Giant rims, and black spokes with aluminum nipples. These are wrapped in Dunlop Geomax AT81, which together, provide maximum, grip, traction, and stability with the absolute and minimum weight.

BRAKES
When it comes to bringing this machine to stop, you'll be happy to have high-tech Brembo brake calipers and lightweight wavy discs doing the business. These also take years of competitive racing into account, providing the perfect combination of ideal pad density and steel quality for longevity and consistent feel.

HANDLEBAR
All KTM XC-F models are equipped with adjustable, high-strength aluminum tapered handlebars made by NEKEN. These can be mounted in four different positions. Standard with ODI vulcanized grip on the right side and a comfortable ODI lock-on grip on the left, your only worry is hanging on, and letting rip.

TRANSMISSION
The KTM 350 XC-F is fitted with an ultra-slick 6-speed semi-close ratio PANKL transmission. An advanced No Dirt gear shift lever design prevents mud and sand from blocking the joint of the lever and guarantees trouble-free shifting. The transmission shaft also features a C4 bearing that has a bigger overlap for reliability, even at extremely tough operating conditions. As with all KTM XC-F models, the engines are fitted with a gear position sensor, giving the option of different engine characteristics for each gear.

ENGINE MANAGEMENT SYSTEM
The state-of-the-art Keihin Engine Management System, with electronic fuel injection, features a 44 mm throttle body with separate systems for cold starting and idle adjustment. The throttle cable mount also allows for easy access and a smooth routing of cables for crisp throttle response, every time.

CYLINDER AND PISTON
Inside the short cylinder, with a bore of 88 mm, thumps a box-type piston made by CP. Its crown geometry is adapted perfectly to the high-compression combustion chamber (14.2:1), where its rigid structure and low weight shine.

CLUTCH
The KTM 350 XC-F is fitted with the extremely durable, KTM-developed DDS clutch (damped diaphragm steel), with a wear-free steel basket and heat-resistant clutch plates. It uses a diaphragm spring instead of the usual coil springs, which results in considerably easier clutch action. Additionally, the Brembo hydraulic system provides easy and precise clutch modulation throughout the entire operating temperature range.
Engine
-
Transmission
6-speed
-
Starter
Electric starter
-
Stroke
57.5 mm
-
Bore
88 mm
-
Clutch
Wet multi-disc DS clutch, Brembo hydraulics
-
Displacement
349.7 cm3
-
EMS
Keihin EMS
-
Design
1-cylinder, 4-stroke engine
Chassis
-
Weight (Without Fuel)
100.5 kg
-
Tank capacity (approx.)
8.5 l
-
Front brake disc diameter
260 mm
-
Rear brake disc diameter
220 mm
-
Front brake
Disc brake
-
Rear brake
Disc brake
-
Chain
5/8 x 1/4"
-
Frame design
Central double-cradle-type 25CrMo4 steel
-
Front suspension
WP XPLOR-USD, Ø 48 mm
-
Ground clearance
370 mm
-
Rear suspension
WP XACT Monoshock with linkage
-
Seat height
950 mm
-
Steering head angle
63.9 °
-
Suspension travel (front)
310 mm
-
Suspension travel (rear)
300 mm
The illustrated vehicles may vary in selected details from the production models and some illustrations feature optional equipment available at additional cost. All information concerning the scope of supply, appearance, services, dimensions and weights is non-binding and specified with the proviso that errors, for instance in printing, setting and/or typing, may occur; such information is subject to change without notice. Please note that model specifications may vary from country to country.The consumption values stated refer to the roadworthy series condition of the vehicles at the time of factory delivery.
